Crimson 3.0 - Download and installation instructions

Release date: 12 May 2025

Programming software for Graphite® HMIs, G3 and G3 Kadet HMI operator panels, Graphite Controllers, Modular Controller, Data Station Plus and E3 I/O™ Modules.

Why Choose Crimson® 3.0?

Crimson® 3.0 is Red Lion’s robust, user-friendly software for configuring and programming a wide range of Red Lion automation products, including:

  • G3 and G3 Kadet HMI operator panels
  • Graphite® HMIs and Controllers (Edge and Core)
  • Modular Controllers
  • Data Station Plus

With its powerful feature set and extensive hardware support, Crimson 3.0 makes integration with industrial systems faster, easier, and more flexible.

Powerful Connectivity with 300+ Protocol Drivers

Crimson 3.0 enables seamless communication with virtually any industrial device or system. Supported protocols include:

  • Modbus RTU and Modbus TCP/IP
  • EtherNet/IP
  • Emerson ROC
  • DNP3 (serial and Ethernet – ideal for rugged environments with Graphite HMIs and controllers)

With support for multiple simultaneous protocol conversions, Crimson 3.0 makes it simple to connect PLCs, PCs, SCADA platforms, and industrial assets across your network.

Intuitive Graphical Interface

Crimson 3.0 features a drag-and-drop graphical user interface designed for ease of use, whether you're a controls engineer or system integrator. The intuitive layout speeds up configuration, reduces errors, and shortens deployment time.

Built-In Logic Control with Crimson Control

With Crimson Control, users can build logic control applications using IEC 61131 programming languages:

  • Ladder Logic
  • Function Block
  • Structured Text
  • Instruction List

Crimson Control delivers PLC/RTU-like functionality without the added hardware cost, including:

  • Native support on Graphite Edge and Core Controllers
  • Easy expansion via Graphite Crimson Control modules for Graphite HMIs
  • Online debugging tools
  • Optional program password protection

This allows cost-effective logic control directly within your HMI or controller.





Device

 Crimson 3.0 Support

 G07, G09, G10, G12, G15

✔  Supported
G3 Kadets

✔  Supported

 G306A

✔  Supported

 G308C/A (Rev 2 only)

✔  Supported

 G310C/S (Rev 2 only)

✔  Supported

 G315

✔  Supported

 G303S/M

X Not supported

 G306M

X Not supported

Data Station Plus (Post-2007)

✔  Supported

 DSPZR

✔  Supported

 E3 I/O Module

✔  Supported

 Modular Controller (Post-2007)

✔  Supported

 PTV

✔  Supported

 StratusConnect MC

✔  Supported



ecatcher-security
How to install

Download and install Crimson 3.0, Gold Build – 714.000

  1. Right-click on the Download link below and select Save As
  2. Select a suitable directory on your PC to save the file
  3. When the download is complete, run the file to install

Note: This build requires a PC running Windows 7 or later. Tablet PCs are not supported at this time.

Timestamp Bug Notification – Fixed in Latest Version

On March 22, 2024, Red Lion devices running Crimson® 3.2, 3.1, 3.0, or 2.0 experienced inaccurate timestamps in data, alarm, and event logs due to an internal software bug. This was not a cybersecurity issue.

Resolved: The bug is fixed in Crimson® firmware version 3.2.1016 and later.
Recommendation: To ensure accurate log data and optimal performance, update to the latest version of Crimson® software.

File Conversion from Crimson 2.0 to 3.0

Crimson 3.0 supports file conversion from most Crimson 2.0 configurations. Supported models include all devices except:

  • Modular Controller
  • G303
  • G306M

For these devices, continue using Crimson 2.0.


Revision history

File Build Filetype Size
Crimson Setup 714.0.0
3.0.714.0 .exe 170.3 MB
Download
Crimson 3.0 - Release Notes
.pdf 609.5 KB
Download
Crimson Setup 3.0.711.0
3.0.711.0 .exe 170.1 MB
Download
Crimson 3.0 - Release Notes
.pdf 609.5 KB
Download
